4 Channel PoE Network Video Recorder with 2 HD Bays, HDMI, Inc 500GB HD

4 Channel PoE Network Video Recorder with 2 HD Bays, HDMI


SCW-CASSOWAY-04
$541.72

Product Details

16CH, PoE, 2HD Bays, HDMI
  • Up to 4 channel with 1080p realtime live view
  • H.264/MJPEG dual codec decoding
  • Max 120fps @ 1080p, 240fps @ 720p, 480fps @ D1 preview & recording
  • All channel simultaneous realtime playback, GRID interface & smart search
  • Support Multi-brand network cameras: ClearView, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videosec, Vivotech and etc.
  • ONVIF Version 2.0 conformance
  • 3D intelligent positioning with ClearView PTZ camera
  • Support 2 SATA HDDs up to 8TB, 1 eSATA up to 16TB, 3 USB2.0
  • Support IPC UPnP, 4 PoE ports
  • Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS


Specifications

System
Main Processor Dual-core embedded processor
Operating System Embedded LINUX
Video & Audio
IP Camera Input 4 channel
Two-way Talk 1 channel Input, 1 channel Output, RCA
Display
Interface 1 HDMI, 1 VGA
Resolution 1920x1080, 1280x1024, 1280x720, 1024x768
Display Split 1/4
OSD Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Recording
Compression H.264 / MPEG4
Resolution 1080P(1920x1080) / 720P(1280x720) / D1 (704x576 / 704x480)
Record Rate 400/480fps @ D1, 200/240fps @ 720P , 100/120fps @ 1080P
Bit Rate 48 ~ 8192kbps
Record Mode Manual, Schedule(Regular(Continuous), MD, Alarm), Stop
Record Interval 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
Video Detection & Alarm
Trigger Events Recording, PTZ, Tour, Alarm, Video Push, Email, FTP, Spot, Buzzer & Screen tips
Video Detection Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank
Alarm Input 3 channel
Relay Output 1 channel
Playback & Backup
Sync Playback 1/4/9/16
Search Mode Time/Date, Alarm, MD & Exact search (accurate to second), Smart search
Playback Function Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom
Backup Mode USB Device / eSATA Device / Network
Network
Ethernet RJ-45 port (10/100M/1000M)
PoE 4 ports (IEEE802.3af)
Network Function HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Alarm Server, IP Search(Support Dahua IP camera, DVR, NVS etc)
Max. User Access 20 users
Smart Phone iPhone, iPad, Android, Windows Phone
Storage
Internal HDD 2 SATA ports, up to 8TB
External HDD 1 eSATA port (Max 4 SATA HDDs), up to 16TB
Auxiliary Interface
USB Interface 3ports (1 Rear), USB2.0
RS232 1 port, For PC communication & Keyboard
RS485 1 port, For PTZ control
General
Power Supply NVR: DC12V
PoE Switch: DC48V
Power Consumption NVR: 20W(without HDD)
PoE Port: Max.15 (each)
Working Environment -10 ~+55°C / 10~90%RH / 86~106kpa
Dimension (W×D×H) 100mm x 220mm x 146mm
Weight 1.6KG(without HDD)
