Specifications
Type: PIR Motion Detector Camera
Pick-up device: 1/3" CCD image sensor
Picture elements : EIA/NTSC: 512 H x 492 V - CCIR/PAL: 512 H x 582 V
Note: PAL only available as special order.
Horizontal resolution: 420 TVL
Minimum Illumination: 0.1 Lux
Horizontal Sync. frequency: EIA/NTSC: 15.734 KHZ - CCIR/PAL: 15.625 KHZ
Vertical frequency : EIA/NTSC: 60 HZ - CCIR/PAL: 50 HZ
Clock frequency: EIA/NTSC: 19.0699 MHZ - CCIR/PAL: 18.9375 MHZ
Lens: 3.7mm Pinhole Lens
Video output: 1Vp-p , 75 Ohms
Gamma: 0.45
Power supply : DC12V
Power Consumption: 150 mA
Storage Temperature : -30ºC ~ 60ºC
Operation Temperature : -10ºC ~ 45ºC
