Specifications
Video import: 1Vp-p/75 ohms, 8-channel
Video export: 1Vp-p/75 ohms, 1-channel
Image degree of separation: > or =40dB
Signal bandwidth: 2MHz, +/-3dB
Switching time: 1 sec-45 secs
Channel switch: side road/automatic
Input voltage: 110V/50Hz
Maximum signal input: 2Vp-p
Audio input: 2Vp-p/75 ohms
Video gain: 0.8Vp-p, 1.4Vp-p
Body construction: iron substrate electrostatic coating
Water Resistance : IP 55
Construction : Aluminum, with off-white baked enamel finish
Color: White
Dimensions: 188 x 265 x 45mm
Operational temperature: -20 to +60 degrees Celsius
* Pictures and specifications are subject to change
